ROYAL Wall Bracing Props are durable, lightweight diagonal braces made from galvanised steel, designed to provide fast and effective support for a wide range of vertical wall systems. Ideal for bracing formwork walls, columns, and lightweight pre-fabricated wall panels such as AFS, Dincel, Rediwall, and Ritek, these props help maintain vertical alignment and resist the pressure of wet concrete during pours.
Each ROYALbracing prop features a top turnbuckle for quick on-site adjustment, and both top and bottom plates come with nail and screw holes for simple and secure installation. Available in multiple size ranges and Safe Working Load (SWL) capacities, they offer a flexible solution for many bracing scenarios.
Features + Benefits:
Galvanised Steel Construction: Rust-resistant and built for long-term durability.
Quick Adjustment: Integrated turnbuckle for fast alignment tweaks.
Versatile Applications: Compatible with a range of pre-cast and in-situ walling systems.
Easy Assembly: Plates include fixing holes for nails or screws.
Multiple Sizes: Available in various lengths and load ratings to suit project needs.
Product Uses:
Used to brace and align concrete formwork, tilt-up panels, and pre-fabricated walling systems during concrete placement and curing.
Specifications:
| Description |
Size Range (mm) |
SWL (kN) |
Weight (kg) |
Code Number |
| ROYAL Bracing Prop 30 x 30 Mini |
1270–1500 |
10 |
6.0 |
BRPROP30MINI |
| ROYAL Bracing Prop 40 x 40 |
2730–3120 |
18 |
13.0 |
BRPROP40 |
| ROYAL Bracing Prop 60 x 60 |
2650–2880 |
14.5 |
29.0 |
BRPROP60 |
| Tilt Panel Bracing Prop Mini |
2400–4100 |
35 |
36.0 |
PROPPMINI |
| Tilt Panel Bracing Prop Standard |
4400–7000 |
35 |
61.0 |
PROPPSTD |
